Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 180mm -
Travel Rear 180mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Spicy Full Carbon 180mm travel (29’’), pressfit, boost, metric, Thru axle
Suspension Fork
RockShox ZEB Ultimate Charger 3 RC2 29” 15x110 DebonAir™ 180mm (29”) 44mm offset
Rear Shock
RockShox Vivid Air 2 Ultimate, 2-Pos Lever, 205x65mm Trunnion
Drivetrain
Rear Derailleur
SRAM XO1 Eagle 12spd
Shift Levers
SRAM XO1 Eagle Trigger Lunar 12s
Cassette
SRAM XG1275 10-52T 12s
Crank
SRAM X1 Carbon Eagle DUB 32T 165mm (XS,S,M), 170mm (L,XL)
Bottom Bracket
SRAM DUB BSA 73 MTB Wide
Chain
SRAM XO1 Eagle 12s
Pedals
NW-91K
Wheels
Rims
DT Swiss EXC1501 SPLINE® 622x30c, SRAM XD, 6 bolts
Tires
Schwalbe, front: 62-622, MAGIC MARY Evo, 67TPI, Super Trail, Addix Ultra soft, TR / rear: 65-584, BIG BETTY, 67TPI, Super Trail, Addix soft, TR
Brakes
Brakes
SRAM CODE Silver Stealth 4 pistons
Brake Levers
SRAM CODE Silver Stealth 4 pistons
Cockpit
Stem
Renthal Apex, Ø: 35mm, L: 33mm (XS,S), 40mm (M,L,XL)
Handlebar
Renthal Fatbar, Width: 800mm, Rise: 30mm, Ø: 35mm
Grips
Lapierre grips anodized, S/M: small diameter, L/XL: large diameter
Seat
Saddle
WTB Volt 142mm
Seatpost
TranzX RAD+ dropper, Ø: 31.6mm, travel 125mm (XS,S), 150mm (M), 170mm (L), 200mm (XL)
