last CELOS 2024
2024 Mountain
Estimate price |
8,010$
Weight | 9.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox SID Ultimate
-
Groupset SLX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LAST CELOS
Suspension Fork
Rock Shox SID Ultimate 120 mm
Drivetrain
Rear Derailleur
Shimano SLX - crank length 175 mm
Cassette
Shimano SLX - crank length 175 mm
Crank
Shimano SLX - crank length 175 mm
Bottom Bracket
BSA, 73 mm
Chain Guide
no chain guide
Pedals
no pedals
Wheels
Rims
DT Swiss E1900 - 29 - Shimano compatible
Tires
29'' to 2,5'' width (depends on tire/rim combination)
Brakes
Brakes
FORMULA CURA 4 BRAKES
Cockpit
Stem
Reverse Black-One D-2 - 35 mm
Handlebar
Reverse Base - 18 x 790 mm
Grips
Ergon GE 10 EVO
Headset
IS41, IS52
Seat
Saddle
Ergon SM 10 Enduro Comp
Seatpost
BikeYoke seatclamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 170 | 180 | 190 | 200 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.309 mm | 1.276 mm | 1.218 mm | 1.159 mm |
| Bottom Bracket Height | 415 mm | 415 mm | 414 mm | 414 mm |
| Front Center | 750 mm | 779 mm | 814 mm | 851 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 151 mm | 151 mm | 152 mm | 154 mm |
| Stack | 598 mm | 611 mm | 620 mm | 628 mm |
| Reach | 457 mm | 479 mm | 509 mm | 542 mm |
| Seat Tube Angle | 78.7 ° | 78.1 ° | 78.3 ° | 78.4 ° |
| Seat Tube Length | 385 mm | 415 mm | 455 mm | 510 mm |
| Head Tube Angle | 66.4 ° | 66.3 ° | 66.2 ° | 66.1 ° |
| Head Tube Length | 95 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 436 mm | 443 mm |
| Wheelbase | 1177 mm | 1206 mm | 1247 mm | 1291 mm |
| Bottom Bracket Drop | -41 mm | -41 mm | -40 mm | -40 mm |
| Standover Height | 705 mm | 704 mm | 708 mm | 713 mm |
| Wheels | 29" | 29" | 29" | 29" |
