Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 145mm -
Fork RockShox Lyrik Select+
-
Groupset SLX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LAST CINTO V2
Suspension Fork
Rock Shox Lyrik Select+ 150 mm
Rear Shock
Fox Float X - Factory Series
Drivetrain
Rear Derailleur
Shimano SLX - crank length 175 mm
Cassette
Shimano SLX - crank length 175 mm
Crank
Shimano SLX - crank length 175 mm
Bottom Bracket
BSA, 73 mm
Chain Guide
no chain guide
Pedals
no pedals
Wheels
Rims
DT Swiss E1900 - 29 - Shimano compatible
Tires
29" and 27,5" to 2,5" width (depends on tire/rim combination)
Brakes
Brakes
FORMULA CURA 4 BRAKES
Cockpit
Stem
Reverse Black One D-2 - 35mm
Handlebar
Reverse base - 18 x 790 mm
Seat
Saddle
Ergon SM 10 Enduro Comp
Seatpost
Bikeyok Divine - 160 mm incl. Triggy Alpha
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 165 | 175 | 185 | 195 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.343 mm | 1.277 mm | 1.212 mm |
| Bottom Bracket Height | 406 mm | 406 mm | 406 mm | 406 mm |
| Front Center | 760 mm | 789 mm | 825 mm | 862 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 157 mm | 156 mm | 158 mm | 157 mm |
| Stack | 610 mm | 623 mm | 632 mm | 640 mm |
| Reach | 442 mm | 464 mm | 495 mm | 528 mm |
| Seat Tube Angle | 77.5 ° | 77 ° | 77.1 ° | 77.3 ° |
| Seat Tube Length | 385 mm | 415 mm | 455 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 64.9 ° | 64.9 ° |
| Head Tube Length | 95 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 437 mm | 443 mm |
| Wheelbase | 1189 mm | 1218 mm | 1260 mm | 1303 mm |
| Bottom Bracket Drop | -32 mm | -32 mm | -32 mm | -32 mm |
| Standover Height | 721 mm | 720 mm | 724 mm | 733 mm |
| Wheels | 29" | 29" | 29" | 29" |
