Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB Select+
-
Groupset SLX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
LAST TARVO V2
Suspension Fork
Rock Shox ZEB Select+ 170 mm - model 2022
Drivetrain
Rear Derailleur
Shimano SLX - crank length 175 mm
Cassette
Shimano SLX - crank length 175 mm
Crank
Shimano SLX - crank length 175 mm
Bottom Bracket
BSA, 73 mm
Pedals
no pedals
Wheels
Rims
DT Swiss E1900 - 29 - Shimano compatible
Tires
29" and 27,5" to 2,5" width (depends on tire/rim combination)
Brakes
Brakes
SRAM DB8 Brakes
Cockpit
Stem
Reverse Black-One D-2 - 35 mm
Handlebar
Reverse Base - 18 x 790 mm
Grips
Ergon GE 10 EVO
Headset
Cane Creek 40 Series
Seat
Saddle
Ergon SM 10 Enduro Comp
Seatpost
Bikeyok Divine - 160 mm incl. Triggy Alpha
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 165 | 175 | 185 | 195 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.428 mm | 1.39 mm | 1.32 mm | 1.253 mm |
| Bottom Bracket Height | 382 mm | 382 mm | 382 mm | 382 mm |
| Front Center | 767 mm | 796 mm | 836 mm | 869 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 152 mm | 152 mm | 148 mm | 152 mm |
| Stack | 617 mm | 631 mm | 640 mm | 649 mm |
| Reach | 432 mm | 454 mm | 485 mm | 518 mm |
| Seat Tube Angle | 76.5 ° | 76 ° | 76.2 ° | 76.4 ° |
| Seat Tube Length | 385 mm | 415 mm | 455 mm | 510 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 95 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 433 mm | 444 mm |
| Wheelbase | 1198 mm | 1227 mm | 1268 mm | 1312 mm |
| Bottom Bracket Drop | -27 mm | -27 mm | -27 mm | -27 mm |
| Standover Height | 732 mm | 730 mm | 734 mm | 738 mm |
| Wheels | 27" | 27" | 27" | 27" |
