Lauf Elja Trail – Race 2025
2025 Mountain
Estimate price |
5,890$
Weight | 12.14 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select+
-
Groupset X0 Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
156cm - 168cm
MD
165cm - 180cm
LG
177cm - 192cm
XL
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lauf IRM* Elja carbon frame, 29x2.8/3.0" tire clearance**, Boost148, LSP, 120mm travel
Suspension Fork
RockShox Pike Select+, 29x2.8" claimed tire clearance, Boost110, 130mm travel
Rear Shock
RockShox SIDLuxe Select+ 2 Position, 190x45mm
Drivetrain
Rear Derailleur
SRAM Eagle Transmission X0, wireless shifting
Shift Levers
SRAM AXS PODS, wireless shifting
Cassette
SRAM XS-1275 Eagle Transmission Cassette, 12 speed, 10-52t
Crank
SRAM X0 Eagle AXS Transmission Power Meter Crankset 32t, 170mm, 55CL
Bottom Bracket
SRAM DUB BSA73
Chain
SRAM Eagle Transmission X0, flat-top, 118 links
Wheels
Rims
Zipp 1Zero HiTop S, 29", carbon, 6-bolt, XD freehub, tubeless ready
Tires
Goodyear Peak 2.6" Tubeless Complete 120tpi
Brakes
Brakes
SRAM Level Bronze Stealth 4-Piston
Cockpit
Stem
FSA Comet ?35 (S:35mm , M-XL: 50mm)
Handlebar
Lauf Mtn Bar, 780mm wide, Ø35mm
Grips
Lauf bolt-on grips
Headset
FSA Orbit, IS 42/52 (36°lower), damped Honey bearings
Seat
Saddle
Fizik Vento Argo X5 140mm, OEM version
Seatpost
RockShox Reverb AXS, Ø31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.443 mm | 1.366 mm | 1.3 mm | 1.249 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 720 mm | 754 mm | 789 mm | 820 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 120 mm | 120 mm | 122 mm | 122 mm |
| Stack | 599 mm | 608 mm | 619 mm | 628 mm |
| Reach | 415 mm | 445 mm | 476 mm | 503 mm |
| Seat Tube Angle | 77.1 ° | 76.4 ° | 75.8 ° | 75.3 ° |
| Seat Tube Length | 406 mm | 443 mm | 453 mm | 463 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 95 mm | 106 mm | 117 mm | 127 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1153 mm | 1187 mm | 1222 mm | 1253 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Standover Height | 727 mm | 750 mm | 759 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 165 cm | 177 cm | 189 cm |
| Rider Max Height | 168 cm | 180 cm | 192 cm | 200 cm |
