leecougan Lee Cougan E-QUEST Team 2025
2025 E-bike
Estimate price |
5,816$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset SX Eagle -
Suspension Full -
Motor Brose 250W 90Nm mid-drive -
Battery Removable battery BMZ V10 720 W/h and 4 levels of assistance -
Drivetrain 1 × 12 -
Brakes Magura MT5 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alloy
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12V
Shift Levers
Mechanical
Cassette
SRAM SX Eagle, 12V, 11-50T
Crank
SRAM SX Eagle, 12V 34T
Wheels
Rims
29"/27.5"
Brakes
Brakes
Magura MT5 4-Piston
Motor & Battery
Motor
Brose Engine S Mag 250 W with 90 Nm power peak
Battery
Removable battery BMZ V10 720 W/h and 4 levels of assistance
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.449 mm | 1.393 mm | 1.351 mm |
| Stack | 616 mm | 620 mm | 628 mm |
| Reach | 425 mm | 445 mm | 465 mm |
| Top Tube Length | 608 mm | 628 mm | 651 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 115 mm | 115 mm | 125 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1202 mm | 1222 mm | 1232 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
