Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
Comfort and handling. The structural suspension gives comfort and handling, as well as stability and traction on the steepest slopes.
Drivetrain
Shift Levers
Electronic
Cassette
Team Eagle, 10-52T
Crank
Team Eagle 34T
Wheels
Rims
29
Brakes
Brakes
Hydraulic Disc
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.438 mm | 1.374 mm | 1.373 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 687 mm | 713 mm | 723 mm |
| Rake | 41 mm | 41 mm | 41 mm |
| Trail | 100 mm | 100 mm | 100 mm |
| Stack | 616.1 mm | 621.1 mm | 630.5 mm |
| Reach | 428.5 mm | 452 mm | 459.2 mm |
| Top Tube Length | 590 mm | 615 mm | 625 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 475 mm | 515 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1107 mm | 1133 mm | 1143 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
