lemond Bicycles Dutch 2025
2025 E-bike
Estimate price |
5,838$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Apex -
Suspension Rigid -
Motor MAHLE 250W 40Nm hub-drive -
Battery Embedded/down tube; 36V, 250W Panasonic -
Brakes SRAM Apex Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 167cm
MD
165cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber; LeMond Design (Weight limit 250lbs)
Suspension Fork
Carbon fiber; LeMond Design
Drivetrain
Rear Derailleur
SRAM Apex
Shift Levers
SRAM Apex
Cassette
SRAM Apex
Crank
SRAM Apex
Bottom Bracket
SRAM
Chain
SRAM Apex
Pedals
Union SP-880
Wheels
Front Hub
Token D1
Rims
Token G23AR Prime
Tires
LeMond / Panaracer Gravelking Slick+ 700 x 38mm
Brakes
Brakes
SRAM Apex
Brake Levers
SRAM Apex
Cockpit
Handlebar
ESI Fit SG - black
Seat
Saddle
Selle Royal Essenza +
Seatpost
LeMond Carbon 30.9mm
Motor & Battery
Motor
Mahle X35+; Rear hub; 250W – Max. Torque: 40Nm
Battery
Embedded/down tube; 36V, 250W Panasonic
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.941 mm | 1.832 mm | 1.837 mm |
| Trail | 85 mm | 85 mm | 85 mm |
| Stack | 691 mm | 696 mm | 742 mm |
| Reach | 356 mm | 380 mm | 404 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 470 mm | 520 mm | 570 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 255 mm | 260 mm | 310 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1122 mm | 1147 mm | 1191 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 165 cm | cm |
| Rider Max Height | 167 cm | 188 cm | cm |
