Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Litespeed FI Road
Drivetrain
Rear Derailleur
Dura-Ace Di2 R9250 12 spd
Front Derailleur
Dura-Ace Di2 R9250 12 spd
Shift Levers
Dura-Ace Di2 R9270 Di2 spd
Cassette
Dura-Ace R9200 11-30 12 spd
Crank
Dura-Ace R9200 50/34 12 spd
Bottom Bracket
Praxis T47 I.B.
Chain
Shimano M9100 12 spd
Wheels
Rims
DT Swiss E 1800 Spline Disc
Tires
Continental GP5000 30c
Brakes
Brakes
Dura-Ace 9270
Cockpit
Stem
FSA ACR
Handlebar
FSA Energy Alloy Compact
Headset
Token A-Box - Gloss Black
Seat
Saddle
Fizik Vento Argo R5 S-Alloy 140 Black
Seatpost
Litespeed Titanium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.425 mm | 1.446 mm | 1.507 mm | 1.553 mm | 1.61 mm | 1.62 mm |
| Bottom Bracket Height | 328 mm | 328 mm | 328 mm | 328 mm | 329 mm | 329 mm |
| Rake | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm |
| Trail | 117 mm | 114 mm | 105 mm | 102 mm | 101 mm | 102 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 430 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
