Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Ultegra, Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Litespeed Carbon with Fender Mounts
Drivetrain
Rear Derailleur
Ultegra Di2 8150 12 spd
Front Derailleur
Ultegra Di2 8150 12 spd
Shift Levers
Ultegra Di2 8170 12 spd
Cassette
Ultegra R8100 11-34 12 spd
Crank
Ultegra R8100 50/34 12 spd
Bottom Bracket
Praxis
Chain
Shimano M8100 12 spd
Wheels
Rims
DT Swiss E 1800 Spline Disc
Tires
Vittoria Corsa N.EXT TLR 32c BLK
Brakes
Brakes
Ultegra 8170
Cockpit
Stem
FSA Energy
Handlebar
FSA Energy Compact
Headset
Cane Creek 40 Series
Seat
Saddle
WTB Volt Medium Cromoly
Seatpost
FSA SLK Carbon 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.533 mm | 1.579 mm | 1.623 mm | 1.667 mm |
| Bottom Bracket Height | 328 mm | 329 mm | 329 mm | 329 mm | 329 mm |
| Rake | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm |
| Trail | 111 mm | 111 mm | 108 mm | 105 mm | 105 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 6 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
