Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Litespeed Carbon Gravel With Fender Mounts
Drivetrain
Rear Derailleur
SRAM Rival XPLR eTap AXS 12 spd
Shift Levers
SRAM Rival eTap AXS
Cassette
SRAM Rival XPLR 10-44 12 spd
Crank
SRAM Rival 1X 42T 12 spd
Bottom Bracket
SRAM Press-Fit
Chain
SRAM Rival 12 spd
Wheels
Rims
SUNringle Duroc 30 Comp 700c
Tires
Panaracer X1 - 40c Black
Brakes
Brakes
SRAM Rival eTap AXS HRD
Cockpit
Stem
FSA Gossamer
Handlebar
FSA NS Adventure Compact
Headset
Cane Creek 40 Series - Gloss Black
Seat
Saddle
WTB Volt Medium Cromoly Black
Seatpost
FSA Gossamer
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.486 mm | 1.486 mm | 1.513 mm | 1.538 mm | 1.582 mm | 1.625 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm | 342 mm | 342 mm |
| Rake | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm | 5 mm |
| Trail | 129 mm | 125 mm | 122 mm | 118 mm | 115 mm | 112 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 430 mm | 445 mm | 470 mm | 495 mm | 520 mm | 550 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
