Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Litespeed Carbon
Drivetrain
Rear Derailleur
Dura-Ace Di2 R9250 12 spd
Front Derailleur
Dura-Ace Di2 R9250 12 spd
Shift Levers
Dura-Ace Di2 R9270 Di2 spd
Cassette
Dura-Ace R9200 11-30 12 spd
Crank
Dura-Ace R9200 50/34 12 spd
Bottom Bracket
Praxis
Chain
Shimano M9100 12 spd
Wheels
Rims
DT Swiss E 1800 Spline Disc
Tires
Continental GP5000 30c
Brakes
Brakes
Dura-Ace 9270
Cockpit
Stem
FSA SL-K SCR +/- 6 degree
Handlebar
FSA SL-K Carbon Compact
Headset
Chris King InSet 7 Matte Black
Seat
Saddle
Fizik Vento Argo R5 S-Alloy 140 Black
Seatpost
Litespeed Titanium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.392 mm | 1.413 mm | 1.434 mm | 1.449 mm | 1.494 mm | 1.55 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm | 329 mm | 329 mm | 329 mm |
| Rake | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm | 4.5 mm |
| Trail | 104 mm | 101 mm | 97 mm | 97 mm | 97 mm | 99 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 455 mm | 475 mm | 495 mm | 515 mm | 535 mm | 555 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm | 6 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
