Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SLR-grade aluminum, w/ hidden rack mounts
Suspension Fork
Composite, with alloy OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano RS505
Cassette
Shimano 105 11x28, 11-speed
Crank
FSA Omega, 36/46
Bottom Bracket
FSA, Press fit
Chain
KMC X11 EL
Pedals
N/A
Wheels
Front Hub
Giant Sport Tracker Disc, 32h, [F] 12x100mm [R] 12x142mm
Rear Hub
Giant Sport Tracker Disc, 32h, [F] 12x100mm [R] 12x142mm
Rims
Giant SX-2 Disc
Spokes
Stainless Steel, 14g
Tires
Maxxis Mud Wrestler, 700x33
Brakes
Brakes
Shimano RS505, hydraulic disc, 140mm
Brake Levers
Shimano RS505
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, 31.8
Seat
Saddle
Liv Contact Forward
Seatpost
Giant D-Fuse, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.45 mm | 1.47 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 590 mm | 596 mm | 617 mm | 628 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 72 mm | 68 mm | 68 mm | 65 mm |
| Stack | 516 mm | 537 mm | 556 mm | 577 mm |
| Reach | 364 mm | 368 mm | 383 mm | 392 mm |
| Top Tube Length | 509 mm | 524 mm | 544 mm | 559 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 445 mm | 475 mm | 505 mm | 520 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1007 mm | 1013 mm | 1034 mm | 1045 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 734 mm | 759 mm | 785 mm | 800 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Brava SLR completes the Liv Brava model. Liv released 16 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Cyclocross bikes
If you want to purchase a solid Cyclocross bike, it is important to know that the average cost is 2012$. However, this doesn’t mean that if you spend less money on a Cyclocross bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2017 and its price was 1500$. Comparing the average cost of a Cyclocross bike to this one, you will see that Brava SLR price is 34.13% smaller.
Brava SLR components
Fork material
Brava SLR has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The wheels on Brava SLR are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Brava SLR has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Liv Brava SLR bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
