Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Groupset CUES, Shimano -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
SM
159cm - 170cm
MD
165cm - 177cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, 120mm FlexPoint Suspension
Suspension Fork
Giant STL 34, 140mm, Boost 15x110
Rear Shock
Suntour Raidon R, 184x44, custom tuned for Liv
Drivetrain
Rear Derailleur
Shimano CUES RD-U6000, Shadow +
Front Derailleur
N/A
Shift Levers
Shimano CUES SL-6000, 1x10
Cassette
Shimano CUES CS-LG300, 11x48
Crank
Shimano CUES, FC-U6000-1, 30t 27.5": XS: 170mm, S: 170mm, M: 170mm 29": S: 170mm, M: 170mm, L: 170mm
Bottom Bracket
Shimano BB MT501, press fit
Chain
Shimano CUES LG500
Pedals
platform
Wheels
Front Hub
alloy
Rear Hub
alloy
Rims
27.5": Giant AM 27.5, tubeless ready, sleeve-joint rim, 30mm inner width 29": Giant AM 29, tubeless ready, sleeve-joint rim, 30mm inner width
Spokes
Sapim
Tires
27.5": [F] Maxxis Minion DHF 27.5x2.6, EXO, TR, tubeless [R] Maxxis Dissector 27.5x2.6, EXO, TR, tubeless 29": [F] Maxxis Minion DHF 29x2.5 WT, EXO, TR, tubeless [R] Maxxis Dissector 29x2.4 WT, EXO, TR, tubeless
Brakes
Brakes
Shimano BR-MT200, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Giant Contact, 35mm 27.5": XS: 40mm, S: 50mm, M: 50mm 29": S: 50mm, M: 50mm, L: 60mm
Handlebar
Giant Contact TR35, 20mm rise, alloy 27.5": XS: 730mm, S: 750mm, M: 750mm 29": S: 750mm, M: 750mm, L: 780mm
Grips
Giant Sole-O
Seat
Saddle
Liv Sylvia
Seatpost
Giant Contact Switch dropper, remote 27.5": XS: 75mm travel / 30.9 x 295mm S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm 29": S: 100mm travel / 30.9 x 345mm M: 125mm travel / 30.9 x 395mm L: 125mm travel / 30.9 x 345mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | SM | MD | MD | LG |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.49 mm | 1.35 mm | 1.45 mm | 1.34 mm | 1.42 mm |
| Front Center | 675 mm | 712 mm | 691 mm | 734 mm | 707 mm | 755 mm |
| Rake | 43 mm | 51 mm | 43 mm | 51 mm | 43 mm | 51 mm |
| Trail | 103.6 mm | 105.3 mm | 103.6 mm | 105.3 mm | 103.6 mm | 105.3 mm |
| Stack | 557 mm | 611 mm | 562 mm | 620 mm | 571 mm | 629 mm |
| Reach | 401 mm | 409 mm | 415 mm | 427 mm | 427 mm | 444 mm |
| Top Tube Length | 562 mm | 562 mm | 577 mm | 582 mm | 592 mm | 602 mm |
| Seat Tube Angle | 74 ° | 76 ° | 74 ° | 76 ° | 74 ° | 76 ° |
| Seat Tube Length | 380 mm | 405 mm | 406 mm | 420 mm | 445 mm | 440 mm |
| Head Tube Angle | 67.5 ° | 67 ° | 67.5 ° | 67 ° | 67.5 ° | 67 ° |
| Head Tube Length | 95 mm | 105 mm | 100 mm | 115 mm | 110 mm | 125 mm |
| Chainstay Length | 432 mm | 435 mm | 432 mm | 435 mm | 432 mm | 435 mm |
| Wheelbase | 1106 mm | 1144 mm | 1122 mm | 1166 mm | 1138 mm | 1187 mm |
| Bottom Bracket Drop | 20 mm | 40 mm | 20 mm | 40 mm | 20 mm | 40 mm |
| Standover Height | 687 mm | 709 mm | 702 mm | 731 mm | 730 mm | 752 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 159 cm | 165 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 170 cm | 177 cm | 177 cm | 184 cm |
Model Overview
Embolden 2 belongs to the Liv Embolden model. There are 14 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Liv Embolden 2 price was 1662$. Comparing the average cost of a Trail bike to this one, you will see that Embolden 2 price is 66.19% lower.
Overview of components
Rear Shock
The shock that’s installed on this bike is Suntour Raidon R, with a travel distance of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Embolden 2 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Embolden 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 6 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the Embolden 2. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
