Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Force, Force eTap -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes SRAM Force Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 176cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, 12x142mm thru-axle, disc
Suspension Fork
Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Force eTap AXS
Front Derailleur
SRAM Force eTap AXS
Shift Levers
SRAM Force eTap AXS 2x12
Cassette
SRAM Force, 12-speed, 10x33
Crank
SRAM Force D2 DUB, 35/48 with power meter
Bottom Bracket
SRAM, press fit
Chain
SRAM Force D1
Pedals
PEDALS NOT SUPPLIED
Wheels
Front Hub
[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rear Hub
[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rims
Giant SLR 1 50 Carbon Disc WheelSystem, [F] 50mm, [R] 50mm
Spokes
SAPIM CX-Ray
Tires
CADEX Race 25, tubeless, 700x25c (26.5mm), folding
Brakes
Brakes
SRAM Force eTap AXS hydraulic, SRAM PaceLine X rotors [F]160mm, [R]140mm
Brake Levers
SRAM Force eTap AXS hydraulic
Cockpit
Stem
Giant Contact SL Aero
Handlebar
Liv Contact SLR Aero, 31.8mm
Grips
Liv Stratus Elite 2.0
Seat
Saddle
Liv Alcara SL
Seatpost
Giant Vector, composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.397 mm | 1.411 mm | 1.448 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm |
| Front Center | 579 mm | 582 mm | 589 mm |
| Rake | 49 mm | 49 mm | 49 mm |
| Trail | 66.3 mm | 59.9 mm | 56.8 mm |
| Stack | 517 mm | 532 mm | 553 mm |
| Reach | 370 mm | 377 mm | 382 mm |
| Top Tube Length | 508 mm | 524 mm | 540 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 155 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm |
| Wheelbase | 973 mm | 977 mm | 984 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm |
| Standover Height | 731 mm | 761 mm | 787 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 158 cm | 164 cm |
| Rider Max Height | 163 cm | 169 cm | 176 cm |
