Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano 105 Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 169cm
MD
164cm - 176cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, 12x142mm thru-axle, disc
Suspension Fork
Advanced SL-Grade Composite, full-composite OverDrive Aero steerer, 12x100mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 Di2 RD-R7150
Front Derailleur
Shimano 105 Di2 FD-R7150
Shift Levers
Shimano 105 Di2
Cassette
Shimano 105, 12-speed, 11x34
Crank
Shimano 105, 36/52 with Giant Power Pro power meter XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm
Bottom Bracket
Shimano, press fit
Chain
KMC X12L-1
Pedals
platform pedal [GCS,GTS] N/A [all other GSC]
Wheels
Front Hub
[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rear Hub
[F] Giant Low Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 30t ratchet driver, CenterLock, 12mm thru-axle
Rims
Giant SLR 1 50 Carbon Disc WheelSystem, [F] 50mm, [R] 50mm
Spokes
SAPIM CX-Ray
Tires
CADEX Race 25, tubeless, 700x25c (26.5mm), folding
Brakes
Brakes
Shimano 105 Di2 hydraulic, Shimano SM-RT70 rotors [F] 160mm, [R] 140mm
Brake Levers
Shimano 105 Di2
Cockpit
Stem
Giant Contact SL Aero XXS: 80mm, XS: 80mm, S: 90mm, M: 100mm, L: 110mm
Handlebar
Liv Contact SLR Aero, 31.8mm XXS: 360mm, XS: 360mm, S: 380mm, M: 400mm, L: 420mm
Grips
Liv Stratus Elite 2.0
Seat
Saddle
Liv Alcara SL
Seatpost
Giant Vector, composite XXS: 350mm, XS: 350mm, S: 350mm, M: 350mm, L: 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD |
|---|---|---|
| Stack Reach Ratio | 1.411 mm | 1.448 mm |
| Bottom Bracket Height | 266 mm | 266 mm |
| Front Center | 582 mm | 589 mm |
| Rake | 49 mm | 49 mm |
| Trail | 59.9 mm | 56.8 mm |
| Stack | 532 mm | 553 mm |
| Reach | 377 mm | 382 mm |
| Top Tube Length | 524 mm | 540 mm |
| Seat Tube Angle | 74.5 ° | 74 ° |
| Seat Tube Length | 500 mm | 530 mm |
| Head Tube Angle | 72 ° | 72.5 ° |
| Head Tube Length | 135 mm | 155 mm |
| Chainstay Length | 405 mm | 405 mm |
| Wheelbase | 977 mm | 984 mm |
| Bottom Bracket Drop | 70 mm | 70 mm |
| Standover Height | 761 mm | 787 mm |
| Wheels | 700 | 700 |
| Rider Min Height | 158 cm | 164 cm |
| Rider Max Height | 169 cm | 176 cm |
