Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 40mm -
Groupset Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
XS
147cm - 162cm
SM
155cm - 172cm
MD
165cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
CR7V T40, 40mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney TY510
Shift Levers
Shimano EF41, 3x7
Cassette
Shimano TZ500, 14x34
Crank
forged alloy, 28/38/48 XS:170mm, S:170mm, M:175mm
Bottom Bracket
sealed cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
Shimano, alloy, 36h
Rear Hub
Shimano, alloy, 36h
Rims
Giant double-wall aluminum
Spokes
stainless
Tires
Kenda K-192, 700x38c
Brakes
Brakes
alloy, direct pull
Brake Levers
alloy
Cockpit
Stem
MQ-576 adjustable, 25.4mm XS:85mm, S:85mm, M:105mm
Handlebar
alloy, low rise, 25.4mm XS:60cm, S:60cm, M:60cm
Grips
Liv Comfort
Seat
Saddle
Liv Comfort
Seatpost
alloy, 30.9mm XS:400mm, S:400mm, M:400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.602 mm | 1.66 mm |
| Front Center | 621 mm | 632 mm | 654 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 87.1 mm | 83.8 mm | 83.8 mm |
| Stack | 586 mm | 607 mm | 644 mm |
| Reach | 371 mm | 379 mm | 388 mm |
| Top Tube Length | 545 mm | 565 mm | 585 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 355.5 mm | 406 mm | 457 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 130 mm | 150 mm | 190 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1067 mm | 1078 mm | 1100 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 419 mm | 421 mm | 432 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 155 cm | 165 cm |
| Rider Max Height | 162 cm | 172 cm | 182 cm |
