Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 125mm -
Fork Giant Crest 34
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM High
158cm - 169cm
SM Low
158cm - 169cm
MD High
164cm - 175cm
MD Low
164cm - 175cm
LG High
170cm - 181cm
LG Low
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum front and rear triangles, 125mm Maestro Suspension, flip chip – Maestro, 12x148mm thru-axle
Suspension Fork
Giant Crest SL 34 Flotune, 140mm, 44mm offset, RCL damper, Boost 15x110 TA bolt type, tapered
Rear Shock
Giant Crest Flotrac, 185x50, custom tuned for Liv, recommended sag 30%
Drivetrain
Rear Derailleur
Shimano Deore, Shadow +
Front Derailleur
N/A
Shift Levers
Shimano Deore, 1x12
Cassette
Shimano Deore M6100, 10x51
Crank
Praxis Cadet M24 Boost, steel chainring 30t, 52mm chainline S: 170mm, M: 170mm, L: 170mm
Bottom Bracket
Praxis, press fit
Chain
KMC X12
Pedals
N/A
Wheels
Front Hub
[F] Giant MTB alloy, six-bolt, [R] Giant MTB alloy, 72 POE (Points of Engagement), six-bolt, MicroSpline driver body
Rear Hub
[F] Giant MTB alloy, six-bolt, [R] Giant MTB alloy, 72 POE (Points of Engagement), six-bolt, MicroSpline driver body
Rims
Giant TRA wheelset, 6061 alloy, hookless, 30mm inner width, 40mm outer width, 21mm height, Wide Guard Technology
Spokes
Sapim, 28, straight pull, DBL Technology
Tires
[F] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless [R] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
Brakes
Brakes
Shimano BR-MT420, hydraulic, Shimano RT-26 rotors [F]180mm, [R]180mm
Brake Levers
Shimano BL-MT401
Cockpit
Stem
Giant Contact SL 35 S: 50mm, M: 50mm, L: 50mm
Handlebar
Giant Contact TR35, alloy, 35mm, 20mm rise S: 760mm, M: 760mm, L: 780mm
Grips
Liv Tactal Pro Single Lock-On S: 120mm, M/L: 130mm
Seat
Saddle
Liv Sylvia
Seatpost
Giant Contact Switch AT dropper, remote S: 120-150mm travel / 30.9 x 459mm M: 140-170mm travel / 30.9 x 499mm L: 140-170mm travel / 30.9 x 499mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.448 mm | 1.494 mm | 1.411 mm | 1.453 mm | 1.374 mm | 1.417 mm |
| Bottom Bracket Height | 344 mm | 334 mm | 344 mm | 334 mm | 344 mm | 334 mm |
| Front Center | 727 mm | 725 mm | 743 mm | 742 mm | 771 mm | 770 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 117 mm | 122 mm | 117 mm | 122 mm | 117 mm | 122 mm |
| Stack | 614 mm | 620 mm | 618 mm | 625 mm | 632 mm | 639 mm |
| Reach | 424 mm | 415 mm | 438 mm | 430 mm | 460 mm | 451 mm |
| Top Tube Length | 557 mm | 558 mm | 573 mm | 574 mm | 597 mm | 599 mm |
| Seat Tube Angle | 77.8 ° | 77 ° | 77.8 ° | 77 ° | 77.8 ° | 77 ° |
| Seat Tube Length | 425 mm | 425 mm | 435 mm | 435 mm | 460 mm | 460 mm |
| Head Tube Angle | 66.5 ° | 65.8 ° | 66.5 ° | 65.8 ° | 66.5 ° | 65.8 ° |
| Head Tube Length | 105 mm | 105 mm | 110 mm | 110 mm | 125 mm | 125 mm |
| Chainstay Length | 435 mm | 438 mm | 435 mm | 438 mm | 435 mm | 438 mm |
| Wheelbase | 1160 mm | 1160 mm | 1176 mm | 1177 mm | 1204 mm | 1205 mm |
| Bottom Bracket Drop | 30 mm | 40 mm | 30 mm | 40 mm | 30 mm | 40 mm |
| Standover Height | 751 mm | 742 mm | 741 mm | 732 mm | 759 mm | 751 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 158 cm | 164 cm | 164 cm | 170 cm | 170 cm |
| Rider Max Height | 169 cm | 169 cm | 175 cm | 175 cm | 181 cm | 181 cm |
