Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 120mm -
Travel Rear 115mm -
Fork RockShox SID
-
Groupset SLX, Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite front and rear triangles, 115mm FlexPoint Pro Suspension, 12x148mm thru-axle
Suspension Fork
RockShox Sid, 120mm, Boost 15x110mm Maxle Stealth, tapered, 44mm offset, Rush RL damper
Rear Shock
Fox Float SL Performance, 165x45, custom tuned for Liv, recommended sag 25%
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M6100, 1x12
Cassette
Shimano SLX, M7100, 10x51
Crank
Praxis Cadet, 30t, 55mm chainline XS:165mm, S:170mm, M:170mm, L:175mm
Bottom Bracket
Praxis, press fit
Chain
KMC X-12
Wheels
Front Hub
Shimano C500, sealed
Rear Hub
Shimano C500, sealed
Rims
Giant XCT 29, 25mm inner width
Spokes
stainless steel
Tires
Maxxis Aspen 29x2.4, foldable, 120tpi, TLR, EXO, tubeless
Brakes
Brakes
Shimano Deore MT410, hydraulic, Shimano RT-26 rotors [F]180mm, [R]160mm
Brake Levers
Shimano Deore MT401
Cockpit
Stem
Giant Contact SL XC, alloy, 35mm XS: 60mm, S: 60mm, M: 70mm, L: 70mm
Handlebar
Giant Contact XC Flat, alloy, 760x35mm
Grips
Liv XC Pro, 32mm
Seat
Saddle
Liv Grit
Seatpost
Giant Contact Switch Core dropper, remote XS: 100mm travel / 30.9 x 350mm S: 100mm travel / 30.9 x 350mm M: 100mm travel / 30.9 x 350mm L: 120mm travel / 30.9 x 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.475 mm | 1.436 mm | 1.417 mm |
| Bottom Bracket Height | 329 mm | 329 mm | 329 mm |
| Front Center | 690 mm | 706 mm | 723 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 112.2 mm | 112.2 mm | 112.2 mm |
| Stack | 599 mm | 603 mm | 612 mm |
| Reach | 406 mm | 420 mm | 432 mm |
| Top Tube Length | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 95 mm | 105 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1121 mm | 1137 mm | 1154 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Standover Height | 748 mm | 767 mm | 770 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 158 cm | 164 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm |
