Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork RockShox Paragon Gold RL
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, disc
Suspension Fork
RockShock Paragon Gold RL, QR, Solo, Air, 50mm, disc, lockout without rebound
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano CUES
Front Derailleur
N/A
Shift Levers
Shimano CUES, 1x11
Cassette
Shimano CS-LG30010, 11x45
Crank
Shimano U6000-1, 42t XS: 170mm, S: 170mm, M: 170mm, L: 170mm
Bottom Bracket
threaded BB shell
Chain
KMC X11
Pedals
platform
Wheels
Front Hub
alloy, 28h
Rear Hub
alloy, 28h
Rims
Giant SX Disc
Spokes
stainless steel, 14g
Tires
Giant CrossCut, 700x42c, puncture protect
Brakes
Brakes
Shimano BR-MT200, hydraulic disc [F]160mm, [R]160mm
Brake Levers
Shimano BL-MT201
Cockpit
Stem
Giant Sport XS: 70mm, S: 80mm, M: 80mm, L: 90mm
Handlebar
Giant Connect XC, 31.8mm, 9-degree/6-degree rise XS: 640mm, S: 640mm, M: 680mm, L: 680mm
Grips
Liv ErgoContact
Seat
Saddle
Liv Ergo Contact
Seatpost
Giant D-Fuse, composite XS: 300mm, S: 300mm, M: 300mm, L: 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.571 mm | 1.566 mm |
| Front Center | 616 mm | 631 mm | 646 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 85.1 mm | 85.1 mm | 85.1 mm |
| Stack | 601 mm | 611 mm | 625 mm |
| Reach | 378 mm | 389 mm | 399 mm |
| Top Tube Length | 550 mm | 570 mm | 590 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1059 mm | 1074 mm | 1089 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Standover Height | 589 mm | 606 mm | 619 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm |
