Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 2 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminium, disc, stagger
Suspension Fork
SR Suntour NEX 700C, 63mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney RD-TY300
Front Derailleur
Shimano Tourney FD-TY606
Shift Levers
Shimano Altus SL-M315, 2x7
Cassette
CS-HG200, 12x32
Crank
Forged alloy, 30/46
Bottom Bracket
sealed cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
alloy, 32h
Rear Hub
alloy, 32h
Rims
Giant GX Disc
Spokes
Stainless steel
Tires
Giant CrossCut, 700x42c, puncture protect
Brakes
Brakes
Tektro HD-M172, mechanical disc [F]160mm, [R]160mm
Brake Levers
Tektro
Cockpit
Stem
Giant Sport
Handlebar
Giant Sport XC, 31.8mm
Grips
Non-lock ring, Sole-O Grip
Seat
Saddle
Liv Ergo Contact
Seatpost
Giant D-Fuse, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.571 mm | 1.566 mm | 1.54 mm |
| Front Center | 616 mm | 631 mm | 646 mm | 666 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 85.1 mm | 85.1 mm | 85.1 mm | 85.1 mm |
| Stack | 601 mm | 611 mm | 625 mm | 639 mm |
| Reach | 378 mm | 389 mm | 399 mm | 415 mm |
| Top Tube Length | 550 mm | 570 mm | 590 mm | 610 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm | 150 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1059 mm | 1074 mm | 1089 mm | 1109 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 589 mm | 606 mm | 619 mm | 629 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 183 cm |
