Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Yamaha 50Nm hub-drive -
Battery EnergyPak 400, 36V 11.6Ah Rechargeable Lithium-Ion -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
150cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX Aluminium, Overdrive 1½ - 1?" head tube, integrated KS18 kickstand mount
Suspension Fork
SR Suntour NEX E25 63mm travel
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano Alivio, 9-speed
Front Derailleur
-
Shift Levers
Shimano Altus
Cassette
Shimano CS-HG200, 11-36T, 9-speed
Crank
Forged Alloy minimal Q-factor, 42T
Bottom Bracket
-
Chain
KMC e.9 Sport, e-bike optimized
Pedals
Aluminium Platform
Wheels
Front Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rear Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rims
Liv GX03V, 700C Aluminium
Spokes
Stainless steel
Tires
Giant Crosscut Gravel 2, 700x45c (622x45), Tubeless Ready W/O Reflex (GU: w/reflex)
Brakes
Brakes
Tektro HD-M275, hydraulic disc, 160/180mm
Brake Levers
Tektro HD-M275
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect Riser
Grips
Liv Comfort Ergo Microtech Plus
Seat
Saddle
Liv Comfort
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Core, 50Nm, Power by Yamaha
Battery
EnergyPak 400, 36V 11.6Ah Rechargeable Lithium-Ion
Remote
RideDash Plus (optional)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.68 mm | 1.61 mm | 1.61 mm |
| Front Center | 634 mm | 648 mm | 670 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 91.3 mm | 91.3 mm | 91.3 mm |
| Stack | 623 mm | 623 mm | 642 mm |
| Reach | 371 mm | 386 mm | 400 mm |
| Top Tube Length | 549 mm | 569 mm | 589 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 135 mm | 135 mm | 155 mm |
| Chainstay Length | 474 mm | 474 mm | 474 mm |
| Wheelbase | 1101 mm | 1115 mm | 1137 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 620 mm | 600 mm | 588 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 158 cm | 164 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm |
Model Overview
Rove E+ is a Liv E Rove model. There are 3 e-bikes that carry this model name.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
This e-bike was released in 2022 and its price was 2037$. Comparing the average cost of a Hybrid e-bike to this one, you will see that Rove E+ price is 21.75% smaller.
Overview of components
Fork
The fork installed on this bike is the SunTour NEX model. The travel on this model is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
As for the wheels, Liv Rove E+ 2022, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Rove E+ has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 3 sizes. They vary from 150 cm – 175 cm (4.92 ft – 5.74 ft). In short, it won’t be difficult to find the right one for you.
