Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Altus -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
One Size
115cm - 130cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
alloy, rigid
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
N/A
Shift Levers
Shimano REVOSHIFT, 1x7
Cassette
Shimano CS-HG200, 12x32
Crank
alloy forged, 30t, 127mm
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 20", alloy, 28mm inner width
Spokes
stainless, 14g
Tires
Kenda Karma, 20x2.6"
Brakes
Brakes
mechanical disc [F]160mm, [R]160mm rotors
Brake Levers
alloy, junior
Cockpit
Stem
forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Junior
Seat
Saddle
Giant Jr. Sport
Seatpost
alloy, 27.2x250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.431 mm |
| Front Center | 523 mm |
| Rake | 42 mm |
| Trail | 59.8 mm |
| Stack | 448 mm |
| Reach | 313 mm |
| Top Tube Length | 450 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 260 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 365 mm |
| Wheelbase | 887 mm |
| Bottom Bracket Drop | 20 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 130 cm |
