Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour XCT
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
125cm - 145cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
SR XCT L24, coil, 80mm, lockout
Rear Shock
N/A
Drivetrain
Rear Derailleur
microSHIFT Advent
Front Derailleur
N/A
Shift Levers
microSHIFT Advent, 1x8
Cassette
microSHIFT Advent, 12x42
Crank
alloy forged, 30t, 140mm
Bottom Bracket
cartridge
Chain
KMC Z8.3
Pedals
platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 24", alloy, 28mm inner width
Spokes
stainless, 14g
Tires
Kenda Karma, 24x2.2"
Brakes
Brakes
Tektro HD-J285, hydraulic [F]180mm, [R]160mm rotors
Brake Levers
Tektro HD-J285
Cockpit
Stem
forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Junior
Seat
Saddle
Giant Jr. Sport
Seatpost
alloy, two-bolt, 30.9x300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.564 mm |
| Front Center | 570 mm |
| Rake | 42 mm |
| Trail | 79.4 mm |
| Stack | 524 mm |
| Reach | 335 mm |
| Top Tube Length | 495 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 410 mm |
| Wheelbase | 978 mm |
| Bottom Bracket Drop | 30 mm |
| Wheels | 24" |
| Rider Min Height | 125 cm |
| Rider Max Height | 145 cm |
