Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
XS
148cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 12x142mm thru-axle, disc
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Cues U6020
Front Derailleur
N/A
Shift Levers
Shimano Cues U6000 1x11
Cassette
Shimano CSLG40011, 11x45
Crank
FSA Omega AGX+, 42t XS: 165mm, S: 165mm, M: 170mm, L: 172.5mm
Bottom Bracket
BB-4000
Chain
KMC X11 with Missing Link
Pedals
platform pedal [GT, GU, GV, GC]
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-X2 wheelset
Spokes
stainless
Tires
Maxxis Re-Fuse, wirebead, tubeless, 700x40c
Brakes
Brakes
Tektro HD-R280, hydraulic [F]160mm, [R]160mm
Brake Levers
Tektro hydraulic
Cockpit
Stem
Giant Contact, 8-degree XS: 80mm, S: 80mm, M: 90mm, L: 100mm
Handlebar
Giant Sport, flat, 31.8mm, 9-degree backsweep XS: 600mm, S: 600mm, M: 640mm, L: 640mm
Grips
Liv ErgoContact
Seat
Saddle
Liv ErgoMax
Seatpost
Giant D-Fuse, alloy, XS: 300mm, S: 300mm, M: 300mm, L: 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.474 mm | 1.532 mm | 1.581 mm |
| Front Center | 599 mm | 605 mm | 616 mm | 631 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 72.8 mm | 69.5 mm | 66.2 mm | 66.2 mm |
| Stack | 534 mm | 560 mm | 590 mm | 618 mm |
| Reach | 376 mm | 380 mm | 385 mm | 391 mm |
| Top Tube Length | 525 mm | 540 mm | 560 mm | 580 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 350 mm | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 110 mm | 135 mm | 165 mm | 195 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1014 mm | 1020 mm | 1031 mm | 1046 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 680 mm | 710 mm | 745 mm | 770 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 148 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 183 cm |
