Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset 105 -
Suspension Rigid -
Motor Yamaha 250W 80Nm mid-drive -
Battery Giant EnergyPak 500, 36V Integrated Lithium-Ion -
Drivetrain 2 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum
Suspension Fork
Advanced-Grade Composite,12x100 thru-axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105
Front Derailleur
Shimano 105
Shift Levers
Shimano SL-RS700, 11-Speed
Cassette
Shimano 105, 11-32, 11-Speed
Crank
Giant custom crankset, 34/50T
Bottom Bracket
N/A
Chain
KMC e.11 Turbo, EcoProteq
Pedals
Aluminum Platform
Wheels
Front Hub
Giant Performance Tracker Road, Sealed Bearing
Rear Hub
Giant Performance Tracker Road, Sealed Bearing
Rims
Giant P-R2 Disc
Spokes
Sapim E-Lite [r] Race [f]
Tires
Maxxis Re-Fuse 700x32c Folding Carbon Bead MaxxShield Tubeless Ready
Brakes
Brakes
Shimano MT201 / BR-U300, hydraulic disc, 160mm
Brake Levers
Shimano MT201
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect XC Flat, 640mm
Seat
Saddle
Liv Sport Pro
Seatpost
Giant D-shape, Composite
Motor & Battery
Motor
Giant SyncDrive Pro
Battery
Giant EnergyPak 500, 36V Integrated Lithium-Ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.408 mm | 1.389 mm | 1.409 mm | 1.422 mm |
| Front Center | 604 mm | 614 mm | 620 mm | 641 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68.8 mm | 68.8 mm | 65.6 mm | 65.6 mm |
| Stack | 542 mm | 546 mm | 562 mm | 586 mm |
| Reach | 385 mm | 393 mm | 399 mm | 412 mm |
| Top Tube Length | 540 mm | 550 mm | 560 mm | 580 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 390 mm | 430 mm | 475 mm | 510 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 105 mm | 110 mm | 125 mm | 150 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1050 mm | 1060 mm | 1066 mm | 1087 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 686 mm | 714 mm | 749 mm | 780 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm |
