Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset microSHIFT Advent, FSA -
Suspension Hardtail -
Motor Yamaha 250W 70Nm mid-drive -
Battery Giant EnergyPak 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 163cm
SM
158cm - 169cm
MD
164cm - 175cm
LG
170cm - 181cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX aluminum, Overdrive 1½ - 1?" head tube, 141mm Boost QR, ISS, EnergyPak Plus Range Extender compatible, integrated KSA18 kickstand mount
Suspension Fork
SR Suntour XCM32 NLO DS 15AH2, 27.5 [XS-S] / 29 [M-L], 120mm travel, tapered steerer, lockout
Rear Shock
n/a
Drivetrain
Rear Derailleur
microSHIFT ADVENT, 9-speed
Front Derailleur
n/a
Shift Levers
microSHIFT ADVENT e-optimized
Cassette
microSHIFT ADVENT, 11-42T, 9-speed, e-optimized
Crank
FSA MegaTooth direct-mount 1X steel 36T alloy crank arm
Bottom Bracket
n/a
Chain
KMC e.9 Sport, e-bike optimized
Pedals
Aluminum Platform
Wheels
Front Hub
Shimano MT400 Boost, Center-Lock, 110x15 [XS-S] / Shimano HB-TC500-15 100x15 [M-L] [F], MT200-B 141mm OLD, QR [R]
Rear Hub
Shimano MT400 Boost, Center-Lock, 110x15 [XS-S] / Shimano HB-TC500-15 100x15 [M-L] [F], MT200-B 141mm OLD, QR [R]
Rims
XCT 27.5 [XS-S] / 29 [M-L] Tubeless Ready 25mm e-bike optimized
Spokes
Stainless steel
Tires
Maxxis Rekon 27.5x2.4" [XS-S] / 29x2.4" [M-L], Wire Bead 60TPI
Brakes
Brakes
Tektro HD-M285, hydraulic disc, 180mm
Brake Levers
Tektro HD-M285
Cockpit
Stem
Contact 31.8 alloy
Handlebar
Connect TR Riser 31.8x690mm [XS-S], 750mm [M-L]
Grips
Tactal single lock-on
Seat
Saddle
Liv Sport
Seatpost
Forge alluminum 30.9mm 2-bolt micro adjustable
Motor & Battery
Motor
Giant SyncDrive Sport, 70Nm, powered by Yamaha, PedalPlus 6-sensor technology
Battery
Giant EnergyPak 500Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 250 range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.626 mm | 1.647 mm | 1.547 mm | 1.506 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 329 mm | 329 mm |
| Front Center | 660 mm | 660 mm | 690 mm | 711 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm |
| Trail | 103.8 mm | 103.8 mm | 99.5 mm | 99.5 mm |
| Stack | 621 mm | 626 mm | 625 mm | 634 mm |
| Reach | 382 mm | 380 mm | 404 mm | 421 mm |
| Top Tube Length | 560 mm | 565 mm | 595 mm | 615 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 365 mm | 405 mm | 445 mm | 485 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 115 mm | 105 mm | 115 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1130 mm | 1130 mm | 1161 mm | 1182 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 45 mm | 45 mm |
| Standover Height | 680 mm | 710 mm | 750 mm | 755 mm |
| Wheels | 27" | 27" | 29" | 29" |
| Rider Min Height | 152 cm | 158 cm | 164 cm | 170 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm |
Model Overview
Vall E+ 3 is a Liv E Vall model. There are 9 e-bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail e-bikes average price
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2024 and its price was 3176$. Comparing this to the average Trail e-bike price, we see that the price is 5.95% lower.
Overview of components
Fork
This e-bike has the Suntour XCM fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Vall E+ 3 2024 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Liv Vall E+ 3 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Liv Vall E+ 3 e-bike has 4 sizes, in the range of 152 cm – 181 cm (4.99 ft – 5.94 ft). In short, you can easily find one that suits you.
