Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
carbon
Drivetrain
Rear Derailleur
SRAM Red AXS 36T
Shift Levers
SRAM Red AXS
Cassette
SRAM X1290 11-33T
Crank
SRAM Red AXS 50/37T (XXS - 48/35T)
Bottom Bracket
PRAXIS T47
Chain
SRAM Red AXS
Wheels
Rims
LOOK R50D Carbon
Tires
Continental GP 5000 TLR 28 mm
Brakes
Brakes
Rim
Cockpit
Stem
LOOK Aero Combo Stem
Handlebar
LOOK Aero Combo Handlebars
Seat
Saddle
Selle Italia SLR Boost Superflow
Seatpost
LOOK Aero Post 4 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.346 mm | 1.35 mm | 1.377 mm | 1.404 mm | 1.429 mm | 1.452 mm |
| Bottom Bracket Height | 260 mm | 263 mm | 263 mm | 265 mm | 265 mm | 268 mm |
| Front Center | 569.8 mm | 569.8 mm | 587.6 mm | 586.7 mm | 603.9 mm | 621.6 mm |
| Rake | 56.3 mm | 50 mm | 50 mm | 43 mm | 43 mm | 43 mm |
| Trail | 59.8 mm | 59.8 mm | 59.8 mm | 59.3 mm | 59.3 mm | 59.3 mm |
| Stack | 486.2 mm | 501.2 mm | 525.2 mm | 549.2 mm | 573.2 mm | 597.2 mm |
| Reach | 361.3 mm | 371.3 mm | 381.3 mm | 391.2 mm | 401.2 mm | 411.2 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 463 mm | 479.6 mm | 504.4 mm | 529.9 mm | 554.8 mm | 579.7 mm |
| Head Tube Angle | 70.7 ° | 71.8 ° | 71.8 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 77.9 mm | 90.4 mm | 115.6 mm | 136.7 mm | 161.8 mm | 189.5 mm |
| Bottom Bracket Drop | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
