Magnum Low Rider 2019
2019 E-bike
Estimate price |
2,249$
Weight | 27.17 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 75mm -
Fork RST
-
Groupset Shimano -
Suspension Hardtail -
Motor 500W 90Nm hub-drive -
Battery Weight: 9.2 lbs (4.17 kg), Brand: Samsung, LG, Panasonic, Voltage: 48 volts, Amp Hours: 13 ah, Watt Hours: 624 wh, Chemistry: Lithium Nickel Cobalt Manganese (Li-NCM) -
Drivetrain 1 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum Alloy
Suspension Fork
RST Neon-TNL Spring Suspension, 75mm Travel, Compression Clicker with Lockout, Preload Adjust, 25mm Steel Stanchions, 100 mm Hub Spacing, 9mm Axle with Quick Release Skewer
Drivetrain
Shift Levers
Shimano RevoShift Half-Grip Twist Shifter on Right
Cassette
8 Speed 1x8 Shimano Acera Derailleur, 11-32 Tooth Nickel Plated Cassette
Crank
Prowheel Ounce, Forged Alloy, 170mm Length, Square Taper Bottom Bracket, 48 Tooth Chainring with Alloy Guard
Pedals
Wellgo VB087 Aluminum Alloy Platform, Black, Fixed Pins
Wheels
Rims
Aluminum Alloy, Double Walled, Machined Sidewalls, 24.5mm Outer Width, 36 Hole
Spokes
Stainless Steel, 13 Gauge, Silver with Adjustable Nipples
Tires
Schwalbe Balloon Big Ben, 26" x 2.15" (55-559)
Cockpit
Stem
Promax Quill Style, Tool-Free Adjustable Angle, 100mm Length, 25.4mm Clamp Diameter
Handlebar
High-Rise, Aluminum Alloy, 670mm Length
Grips
Imitation Leather, Ergonomic, Stitched
Headset
Neco, Threadless, Internal Cups, Straight 1-1/8"
Seat
Saddle
Selle Royal Cruiser Comfort, Rubber Bumpers, Imitation Leather
Seatpost
Promax, Aluminum Alloy
Motor & Battery
Motor
Weight: 10.1 lbs (4.58 kg), Brand: Das-Kit, Type: Rear-Mounted Geared Hub, Nominal Output: 500 watts, Peak Output: 700 watts, Torque: 90 Newton meters
Battery
Weight: 9.2 lbs (4.17 kg), Brand: Samsung, LG, Panasonic, Voltage: 48 volts, Amp Hours: 13 ah, Watt Hours: 624 wh, Chemistry: Lithium Nickel Cobalt Manganese (Li-NCM)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 72cm |
|---|---|
| Wheels | 26" |
| Rider Min Height | 120 cm |
About this model
Low Rider belongs to the Magnum E Low model. Magnum launched 1 e-bike of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for General Urban e-bikes
Our math shows that the average cost of a dependable General Urban e-bike is 2098$. However, even though the average price of a General Urban e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Magnum released this model in 2019, its price was 2249$. Doing a quick comparison, we notice that Low Rider price is 7.2% higher than the average cost of a General Urban e-bike.
Average weight for General Urban e-bikes
General Urban e-bikes have an average weight of 24.08 kg (53.09 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
considerably heavier than average, Low Rider has a weight of 27.17 kg (59.9 lbs). In conclusion, the average General Urban e-bike weighs 12.83% less than Low Rider.
Low Rider components
Fork
The fork installed on this bike is the RST model. The travel on this model is 75mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Low Rider has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
As for the wheels, Magnum Low Rider 2019, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
