Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 50mm -
Fork SunTour XCT
-
Groupset Altus, Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
One Size
124cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 24” Wheels, IS Seatstay Disc Mount, 135mm Dropouts
Suspension Fork
SR Suntour XCT Jr 24", Pre-Load Adjust Coil Spring, 50mm Travel
Drivetrain
Rear Derailleur
Shimano Altus, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Revo Twist 1x7-Speed
Cassette
Shimano HG-20 7-Speed, 12-32T
Crank
Forged Alloy, 30T, 152mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Tires
Vee Tire Crown Gem, 24”x2.25”, Wire Bead
Brakes
Brake Levers
Kids Specific Short Reach Alloy Lever
Cockpit
Stem
Marin Alloy, 60mm
Handlebar
Marin Riser, 30mm Rise, 590mm Width
Grips
Marin Dual Density
Headset
FSA, Threaded
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 283 mm |
| Front Center | 548 mm |
| Rake | 40 mm |
| Stack | 508.75 mm |
| Reach | 337.92 mm |
| Top Tube Length | 491 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 321 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 406 mm |
| Wheelbase | 952 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 587 mm |
| Wheels | 24" |
| Rider Min Height | 124 cm |
| Rider Max Height | 142 cm |
Model Overview
Bayview Trail is part of the Marin Bayview model. Marin launched 17 bikes of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 489$. Comparing this to the average Mountain bike price, we see that the price is 25.97% smaller.
Overview of components
Fork
The Bayview Trail comes factory-installed with the SunTour XCT fork. This has a travel range of 50mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The wheels on Bayview Trail are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Bayview Trail is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Marin Bayview Trail 2021 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
