Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Tourney -
Suspension Hardtail -
Drivetrain 2 × 7 -
Brakes Tektro Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 27.5”/29" Wheels, Low Standover, 68mm BB shell, 135mm Forged Dropouts, Chainstay Mounted Disc Brakes
Suspension Fork
SR Suntour XCE Disc, 100mm Travel, Preload Adjustment, 46mm Offset
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano FD-TX600
Shift Levers
Shimano Tourney 2x7-Speed
Cassette
Shimano, CSHG200, 7-Speed, 11-32T
Crank
Alloy Crank, Steel Chainrings, 36/22T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc, 32H
Rear Hub
Forged Alloy, Disc, 32H
Rims
Marin, Double Wall Alloy
Spokes
Black Stainless Steel
Tires
MTB, 27.5/29x2.25"
Brakes
Brakes
Tektro MDM280 Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 31.8mm, 45mm
Handlebar
Marin 31.8 Riser, 12mm Rise, 780mm Width
Grips
Marin MTB, Closed End
Headset
FSA No.10-P
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 27.2mm
