Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Lightweight Aluminum, Low Standover, 16” Wheels, Single Speed, Rim Brake
Suspension Fork
Series 1 Aluminum, Rim brake
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
Single Speed Freewheel, 20T
Crank
Forged Alloy, 26T, 90mm Length
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC 1-Speed
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Aluminum Alloy, 16H
Rear Hub
Forged Aluminum Alloy, 16H
Rims
Aluminum, CNC Brake Surface
Spokes
14g Stainless Steel
Tires
Marin X Vee Tire Co. Speedster, 16x2.0”
Brakes
Brakes
Linear Pull, Alloy
Brake Levers
Kid's Specific Short Reach Alloy Lever
Cockpit
Stem
Alloy, 40mm
Handlebar
Riser, 40mm Rise, 580mm Width, 19mm OD Grip Section
Grips
Single Densitiy, Thin Diameter Grip
Headset
Threadless
Seat
Saddle
Marin 16" Integrated Saddle/Post
Seatpost
Aluminum, 25.4mm, Integrated Saddle/Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.289 mm |
| Bottom Bracket Height | 182 mm |
| Front Center | 419 mm |
| Rake | 25 mm |
| Stack | 348 mm |
| Reach | 270 mm |
| Top Tube Length | 383 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 230 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 80 mm |
| Chainstay Length | 293 mm |
| Wheelbase | 710 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 373 mm |
| Wheels | 16" |
