Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, microSHIFT Mezzo -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Lightweight Aluminum, Low Standover, 20” Wheels, Replaceable Derailleur Hanger, Rim Brake
Suspension Fork
Series 1 Aluminum, Rim brake
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Microshift TS39 Short-Reach 7-Speed
Cassette
SunRace, 7-Speed, 11-34T
Crank
Forged Alloy, 34T, 140mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC 7-Speed
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Aluminum Alloy, 28H
Rear Hub
Forged Aluminum Alloy, 28H
Rims
Aluminum, CNC Brake Surface
Spokes
14g Stainless Steel
Tires
Marin X Vee Tire Co. Speedster, 20x2.0”
Brakes
Brakes
Linear Pull, Alloy
Brake Levers
Kid's Specific Short Reach Alloy Lever
Cockpit
Stem
Alloy, 40mm
Handlebar
Marin Riser, 50mm Rise, 580mm Width, 19mm OD Grip Section
Grips
Single Densitiy, Thin Diameter Grip
Headset
Threadless
Seat
Saddle
Marin 20" Integrated Saddle/Post
Seatpost
Aluminum, 27.2mm, Integrated Saddle/Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.361 mm |
| Bottom Bracket Height | 227 mm |
| Front Center | 487 mm |
| Rake | 40 mm |
| Stack | 407 mm |
| Reach | 299 mm |
| Top Tube Length | 424 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 280 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 355 mm |
| Wheelbase | 840 mm |
| Bottom Bracket Drop | 30 mm |
| Standover Height | 450 mm |
| Wheels | 20" |
