Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, 16" Kids
Suspension Fork
Steel Straight Blade, 1 1/8" Threadless Steerer Tube
Drivetrain
Crank
Alloy 3-Piece, 102mm; 32t chainring
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC C-410 Single Speed
Pedals
Kids Specific Nylon
Wheels
Front Hub
Steel 16H
Rear Hub
Steel 16H Single Speed
Rims
Marin Aluminum w/ Machined Sidewalls
Tires
Marin/Vee Tire Speedster, 16"x2.0"
Brakes
Brakes
Tektro Linear Pull
Brake Levers
Tektro Kids Specific Short Reach Alloy
Cockpit
Stem
Aluminum BMX Style
Handlebar
BMX Riser, Steel
Grips
Kids Specific
Headset
FSA No. 8B, Threadless, 1 1/8"
Seat
Saddle
Marin Kids w/ Integrated Seat Post
Seatpost
25.4mm Steel, Integrated w/ Saddle
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.206 mm |
| Bottom Bracket Height | 205 mm |
| Front Center | 425 mm |
| Rake | 23 mm |
| Stack | 346 mm |
| Reach | 287 mm |
| Top Tube Length | 400 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 230 mm |
| Head Tube Angle | 72 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 296 mm |
| Wheelbase | 721 mm |
| Bottom Bracket Drop | 3 mm |
| Standover Height | 420 mm |
| Wheels | 16" |
