Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney -
Suspension Rigid -
Drivetrain 1 × 6 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Aluminum, 24” Wheels, Replaceable Derailleur Hanger, Rim Brake
Suspension Fork
Steel Blade, Rim Brake
Drivetrain
Rear Derailleur
Shimano Tourney 6-Speed
Shift Levers
Shimano Revoshift 6-Speed
Crank
Forged Alloy, 32T, 152mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC 6-Speed
Pedals
Kids Specific Nylon
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Aluminum, CNC Brake Surface
Spokes
14g Stainless Steel
Tires
Marin/Vee Tire Speedster, 24"x2.0"
Brakes
Brakes
Linear Pull, Alloy
Brake Levers
Kid's Specific Short Reach Alloy Lever
Cockpit
Stem
Alloy, 40mm
Handlebar
45mm Rise, 580mm Width
Grips
Single Densitiy
Headset
Threadless
Seat
Saddle
Integrated Saddle/Post
Seatpost
27.2mm, Integrated Saddle/Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.56 mm |
| Bottom Bracket Height | 269 mm |
| Front Center | 537 mm |
| Rake | 40 mm |
| Stack | 494 mm |
| Reach | 316.6 mm |
| Top Tube Length | 467.67 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 310 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 130 mm |
| Chainstay Length | 405 mm |
| Wheelbase | 939 mm |
| Bottom Bracket Drop | 35 mm |
| Standover Height | 588 mm |
| Wheels | 24" |
