Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 DSX, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Deore, RDM5100, 11-Speed
Front Derailleur
-
Shift Levers
Shimano Deore, SLM5100, 11-Speed
Cassette
Shimano, CSM5100, 11-Speed, 11-51T
Crank
Forged Aluminum, 42T Steel Narrow Wide Chainring
Bottom Bracket
Sealed Cartridge
Chain
KMC X11
Pedals
Nylon Platform
Wheels
Front Hub
Forged Aluminum, 100x12mm, Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, Disc Specific
Tires
WTB Riddler, 700Cx45mm
Brakes
Brakes
Tektro HD-R280 Flat Mount Hydraulic Disc, 160mm Rotor
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin MiniRiser
Grips
Marin MTB
Headset
FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin DSX
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.414 mm | 1.43 mm | 1.445 mm |
| Bottom Bracket Height | 279.5 mm | 279.5 mm | 279.5 mm | 279.5 mm |
| Front Center | 612 mm | 648 mm | 673 mm | 698 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 77 mm | 77 mm | 77 mm | 77 mm |
| Stack | 544.4 mm | 572.5 mm | 600.6 mm | 628.7 mm |
| Reach | 380 mm | 405 mm | 420 mm | 435 mm |
| Top Tube Length | 536.1 mm | 569.2 mm | 592.2 mm | 615.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1024 mm | 1060 mm | 1085 mm | 1110 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 658 mm | 700 | 730 mm | 758 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 195 cm |
