Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Acera, Altus -
Suspension Rigid -
Motor Bafang 250W hub-drive -
Battery Bafang 340Wh, 36V, In-tube -
Drivetrain 1 × 8 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
184cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Fitness, E-Bike Specific, 6061 Aluminum, 700c Wheels, Disc Specific, Fitness Geometry, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
6061 Aluminum, Straight-Blade, Disc Mount, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Acera, 8-Speed, Wide Range
Front Derailleur
-
Shift Levers
Shimano Altus 8-Speed RapidFire
Cassette
Shimano HG-400, 8-Speed, 11-40T
Crank
Alloy Crank, Steel 42T Chainring, Ring Guard
Bottom Bracket
Integrated Torque Sensing, Sealed Cartridge Bearings, Square Taper
Chain
KMC X8
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Bafang 250 Watt Hub Motor, 36H, North America Class 1 (20mph, 32km/h), and 16mph, 25km/h for the rest of the world
Rims
Marin Aluminum Double Wall, Disc Specific
Spokes
14g Stainless Steel
Tires
Vee Tire, City Cruz, 700Cx40mm, Puncture Protection, Reflective Sidewall, Wire Bead
Brakes
Brakes
Tektro HDM-275 Hydraulic Disc, 160mm Rotor
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin Alloy
Handlebar
Marin Alloy Flat
Grips
Marin County
Headset
FSA, Orbit CE No.8B
Seat
Saddle
Marin Fitness
Seatpost
Marin Alloy, 27.2mm
Motor & Battery
Motor
Bafang 250 Watt Hub Motor, 36H, North America Class 1 (20mph, 32km/h), and 16mph, 25km/h for the rest of the world
Battery
Bafang 340Wh, 36V, In-tube
Remote
Bafang Handlebar Mount LED Switch & Display
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.405 mm | 1.384 mm | 1.401 mm |
| Bottom Bracket Height | 283.5 mm | 283.5 mm | 283.5 mm | 283.5 mm |
| Front Center | 634 mm | 661 mm | 687 mm | 712 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 71 mm | 71 mm | 71 mm | 71 mm |
| Stack | 571.3 mm | 590.1 mm | 609 mm | 637.3 mm |
| Reach | 399.5 mm | 420 mm | 440 mm | 455 mm |
| Top Tube Length | 569 mm | 595 mm | 620 mm | 644 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 175 mm | 195 mm | 225 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1070 mm | 1097 mm | 1123 mm | 1148 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 705 mm | 745 mm | 779 mm | 808 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 167 cm | 177 cm | 187 cm | 190 cm |
