Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 40mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, Girls Specific Frame, 20” Wheels, V-Brake Mounts, 135mm Dropout
Suspension Fork
SR Suntour M3010, 40mm Travel
Drivetrain
Rear Derailleur
Shimano Tourney, RD-TY300
Front Derailleur
-
Shift Levers
Shimano Revo Twist 7-Speed
Cassette
Shimano HG20, 12-28T
Crank
Forged Alloy, 36T, 140mm, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Kids Specific Resin Pedal
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Marin, Double Wall Alloy
Tires
Schwalbe Little Joe, 20”x2.0”, Reflective Sidewall
Brakes
Brakes
Forged Alloy Linear Pull
Brake Levers
Kids Specific Short Reach Alloy Lever
Cockpit
Stem
Marin Alloy
Handlebar
Marin Riser, 30mm Rise, 590mm Width
Grips
Marin Dual Density
Headset
FSA, Threaded
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" |
|---|---|
| Stack Reach Ratio | 1.49 mm |
| Bottom Bracket Height | 232 mm |
| Front Center | 484 mm |
| Rake | 33 mm |
| Stack | 432.39 mm |
| Reach | 290.66 mm |
| Top Tube Length | 425 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 308 mm |
| Head Tube Angle | 70 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 373 mm |
| Wheelbase | 855 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 504 mm |
| Wheels | 20" |
Model Overview
Hidden Canyon 20″ Girls belongs to the Marin Hidden model. There are 13 bikes that carry this model name.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Youth bikes
Our math shows that the average cost of a dependable Youth bike is 278$. However, this doesn’t mean that if you spend less money on a Youth bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Hidden Canyon 20″ Girls components
Fork
The SunTour is included from the factory. It has a travel distance of 40mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Hidden Canyon 20″ Girls are the 20″ aluminum type. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Hidden Canyon 20″ Girls is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
