Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
SM
149cm - 159cm
MD
156cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 700C Wheels, Step Through Design, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent X 10-Speed Wide Range
Front Derailleur
-
Shift Levers
microSHIFT Advent X 10-Speed
Cassette
microSHIFT 10-Speed, 11-48T
Crank
Forged Alloy Crank, Steel Narrow Wide 38T Chainring
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X10
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Ci. GPVee, 700Cx40mm, Wire Bead, Flat Protection, Mixed Terrain Ready
Brakes
Brakes
Tektro MDM280 Mechanical Disc, 160mm Rotor
Brake Levers
Aluminum Lever
Cockpit
Stem
Marin Aluminum, 31.8mm Clamp
Handlebar
Marin Alloy, 30mm Rise, 12? Backsweep
Grips
Marin County
Headset
FSA 888 Threadless
Seat
Saddle
Marin Adventure Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.667 mm | 1.621 mm | 1.606 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 642 mm | 667 mm | 689 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 633.6 mm | 648.4 mm | 666.5 mm |
| Reach | 380 mm | 400 mm | 415 mm |
| Top Tube Length | 567.7 mm | 591.9 mm | 612.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 422 mm | 462 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 190 mm | 205 mm | 225 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1082 mm | 1108 mm | 1130 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 510 mm | 523 mm | 543 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 156 cm | 166 cm |
| Rider Max Height | 159 cm | 169 cm | 177 cm |
