Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Tektro Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 164cm
MD
161cm - 174cm
LG
171cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Butted CrMo, 27.5” Wheels, Mixte Low-Step, Integrated Headset, Disc Brake, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Curved Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent X 10-Speed Wide Range
Front Derailleur
-
Shift Levers
microSHIFT Advent X 10-Speed
Cassette
SunRace 10-Speed, 11-51T
Crank
Forged Alloy Crank, Steel Narrow Wide 38T Chainring
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X10
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, 25mm Internal, Disc Specific
Spokes
14g Stainless Steel
Tires
Vee Tire, GPVee, 27.5x2.35", Wire Bead, Puncture Protection, Mixed Terrain Ready
Brakes
Brakes
Tektro HD-M275 Hydraulic, 180mm Rotor
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy Sweeper
Grips
Marin Adventure
Headset
FSA Orbit CE No.8B
Seat
Saddle
Marin Adventure Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.546 mm | 1.504 mm | 1.478 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm |
| Front Center | 651 mm | 676 mm | 703 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 73 mm | 73 mm |
| Stack | 602.8 mm | 616.8 mm | 635.4 mm |
| Reach | 390 mm | 410 mm | 430 mm |
| Top Tube Length | 568.6 mm | 592.7 mm | 618.2 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 390 mm | 450 mm | 500 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 190 mm | 205 mm | 225 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1080 mm | 1105 mm | 1132 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm |
| Standover Height | 550 mm | 562 mm | 576 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 161 cm | 171 cm |
| Rider Max Height | 164 cm | 174 cm | 180 cm |
