Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Lombard, 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing, Disc Specific Forged Dropouts w/ Mudguard and Rack Mounts
Suspension Fork
6061 Aluminum, Straight-Blade, Post-Mount Disc
Drivetrain
Rear Derailleur
Shimano Sora 9-Speed
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 2x9-Speed
Cassette
Shimano HG-200, 11-34T
Crank
Marin 3D Forged Alloy, 48/32T Chainrings, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner
Tires
Vee Tire Co. G-Sport, 700Cx40mm, Puncture Protection
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano Sora 9-Speed STI
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 16º Flared Drop
Grips
Marin Microfiber Tape
Headset
FSA No.8B
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.39 mm | 1.4 mm | 1.43 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 598 mm | 610 mm | 620 mm | 631 mm | 641 mm | 656 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 65 mm | 64 mm | 64 mm | 65 mm | 64 mm | 64 mm |
| Stack | 532.8 mm | 551.8 mm | 566 mm | 585 mm | 599.2 mm | 623 mm |
| Reach | 393.6 mm | 398.2 mm | 404 mm | 409 mm | 414 mm | 422 mm |
| Top Tube Length | 535 mm | 555 mm | 565 mm | 575 mm | 590 mm | 605 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 162 mm | 177 mm | 202 mm |
| Chainstay Length | 430 mm | 435 mm | 435 mm | 435 mm | 440 mm | 440 mm |
| Wheelbase | 1018 mm | 1035 mm | 1045 mm | 1056 mm | 1071 mm | 1087 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 779 mm | 797 mm | 816 mm | 834 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Lombard 1 completes the Marin Lombard model. 13 bikes variations carry this model name so far.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Urban bikes average price
According to our math, the average price for a trustworthy General Urban bike is 499$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2023 and its price was 1089$. Comparing this to the average General Urban bike price, we see that the price is 118.24% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Lombard 1 components
Fork material
Lombard 1 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The Lombard 1 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lombard 1 has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
