Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Lombard, 6061 Aluminum, 700C Wheels, Relieved Head Tube and BB, Internal Cable Routing, Disc Specific Forged Dropouts w/ Mudguard and Rack Mounts
Suspension Fork
6061 Aluminum, Straight-Blade, Post-Mount Disc
Drivetrain
Rear Derailleur
Shimano Sora 9-Speed
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora 2x9-Speed
Cassette
Shimano HG-200, 11-34T
Crank
Marin 3D Forged Alloy, 48/32T Chainrings, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner
Tires
Vee Tire Co. G-Sport, 700Cx40mm, Puncture Protection
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano Sora 9-Speed STI
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 16º Flared Drop
Grips
Marin Microfiber Tape
Headset
FSA No.8B
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.39 mm | 1.4 mm | 1.43 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 598 mm | 610 mm | 620 mm | 631 mm | 641 mm | 656 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 65 mm | 64 mm | 64 mm | 65 mm | 64 mm | 64 mm |
| Stack | 532.8 mm | 551.8 mm | 566 mm | 585 mm | 599.2 mm | 623 mm |
| Reach | 393.6 mm | 398.2 mm | 404 mm | 409 mm | 414 mm | 422 mm |
| Top Tube Length | 535 mm | 555 mm | 565 mm | 575 mm | 590 mm | 605 mm |
| Seat Tube Angle | 75 ° | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 162 mm | 177 mm | 202 mm |
| Chainstay Length | 430 mm | 435 mm | 435 mm | 435 mm | 440 mm | 440 mm |
| Wheelbase | 1018 mm | 1035 mm | 1045 mm | 1056 mm | 1071 mm | 1087 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 779 mm | 797 mm | 816 mm | 834 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Lombard 1 is part of the Marin Lombard model. Marin released 13 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for General Urban bikes
According to our math, the average price for a trustworthy General Urban bike is 499$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2024, its price was 1089$. If we compare this with the average General Urban bike cost we notice that the price is 118.24% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Lombard 1 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Lombard 1 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
