Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
149cm - 159cm
SM
156cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Butted CrMo, 29” Wheels, Integrated Headset, Disc Brake, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent X 10-Speed
Front Derailleur
-
Shift Levers
microSHIFT Advent X 10-Speed Trail
Cassette
SunRace 10-Speed, 11-51T
Crank
Forged Alloy Crank, Steel Narrow Wide 38T Chainring
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X10
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum, Double Wall, Disc Specific
Tires
Schwalbe Citizen, 700Cx40mm, Reflective Sidewall, Puncture Resistant, Reflective Sidewall
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy Mini Riser
Grips
Marin Custom
Headset
FSA No.8B, Sealed Cartridge Bearings
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.45 mm | 1.41 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 289.5 mm | 289.5 mm | 289.5 mm | 289.5 mm | 289.5 mm |
| Front Center | 636 mm | 669 mm | 701 mm | 734 mm | 766 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 89 mm | 89 mm | 89 mm | 89 mm | 89 mm |
| Stack | 558.7 mm | 577.2 mm | 595.6 mm | 614.1 mm | 632.6 mm |
| Reach | 372 mm | 397 mm | 422 mm | 447 mm | 472 mm |
| Top Tube Length | 533 mm | 563.4 mm | 593.7 mm | 624 mm | 654.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm | 530 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1052 mm | 1084 mm | 1117 mm | 1150 mm | 1182 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 630 mm | 669 mm | 700 | 728 mm | 748 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 156 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 159 cm | 169 cm | 179 cm | 189 cm | 193 cm |
About this model
Muirwoods belongs to the Marin Muirwoods model. Marin launched 13 bikes of this model so far.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin Muirwoods price was 899$. In conclusion, this bike price is 17.98% higher than the price of the average Commuter bike.
Muirwoods components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
As for the wheels, Marin Muirwoods 2024, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Muirwoods has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 149 cm – 193 cm (4.89 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
