Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Double Butted CrMo, 700c/29
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc
Drivetrain
Rear Derailleur
Shimano Alivio Shadow
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus 9-Speed
Cassette
Shimano Alivio 9-Speed, 12-36T
Crank
SR Suntour XCR6, 48/36/26T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC X9
Pedals
Resin Platform
Wheels
Front Hub
Formula, 6-Bolt Disc, 32H
Rear Hub
Formula, 6-Bolt Disc, 32H
Rims
Araya DS700, Double Wall, Disc Specific
Tires
Schwalbe Citizen, 29x1.6”/700x40c, Reflective Sidewall, Kevlar Puncture Protection
Brakes
Brakes
Tektro Auriga Hydraulic Disc, 160mm Rotor
Brake Levers
Tektro Auriga Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Flat Top Riser
Grips
Marin Custom
Headset
FSA No.8D, Sealed Cartridge Bearing
Seat
Saddle
Marin Fitness
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.37 mm | 1.35 mm | 1.37 mm | 1.42 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 617 mm | 634 mm | 650 | 654 mm | 658 mm |
| Rake | 51 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 67 mm | 65 mm | 67 mm | 66 mm |
| Stack | 565 mm | 572 mm | 581 mm | 591 mm | 610 mm |
| Reach | 385 mm | 418 mm | 430 mm | 432 mm | 429 mm |
| Top Tube Length | 548 mm | 588 mm | 603 mm | 613 mm | 628 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 521 mm | 559 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 123 mm | 123 mm | 133 mm | 143 mm | 163 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1050 mm | 1068 mm | 1084 mm | 1088 mm | 1092 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 661 mm | 703 mm | 746 mm | 777 mm | 809 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Muirwoods 29 completes the Marin Muirwoods model. Marin launched 13 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
According to our math, the average price for a trustworthy Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The Muirwoods 29 2016 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Muirwoods 29 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
