Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BT-EN805L, Internal 504Wh -
Drivetrain 1 × 10 -
Brakes TRP Slate EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
Suspension Fork
RockShock 35 Silver R 29", Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset
Rear Shock
X-Fusion 02 PRO R, Compression and Rebound Adjustment, Custom Tune, 210x55 25xM8 Lower Mount & Upper Mount
Drivetrain
Rear Derailleur
Shimano Deore, Direct Attachment, 10-Speed SGS
Shift Levers
Shimano Deore, 10-Speed, I-Spec EV
Cassette
Shimano Deore 10-speed 11-46T
Crank
Shimano EM600, 160mm Length, 38t Chainring
Chain
KMC X-10E, Silver
Pedals
Marin MTB Plastic
Wheels
Front Hub
Shimano FH-TC500, 110x15mm, Centerlock, 32H
Rear Hub
Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body
Rims
Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing
Brakes
Brakes
TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick
Brake Levers
Shimano MT4100 Hydraulic, I-Spec EV Compatible
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips
Marin Grizzly Lock On
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin eMTB Saddle
Seatpost
TranzX, YSP18JL, 1x Remote, Size S 150mm Travel, All Other Sizes 170mm Travel, 30.9mm
Motor & Battery
Motor
Shimano Steps EP6 Drive Unit, 250W, 85Nm
Battery
Shimano BT-EN805L, Internal 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.364 mm | 1.321 mm | 1.289 mm | 1.231 mm |
| Bottom Bracket Height | 348.5 mm | 348.5 mm | 348.5 mm | 348.5 mm |
| Front Center | 760 mm | 784 mm | 809 mm | 843 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 128 mm | 127 mm | 128 mm | 128 mm |
| Stack | 606.98 mm | 614.04 mm | 625.1 mm | 634.16 mm |
| Reach | 445 mm | 465 mm | 485 mm | 515 mm |
| Top Tube Length | 585.13 mm | 607.22 mm | 629.32 mm | 661.41 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 390 mm | 400 mm | 425 mm | 435 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1198 mm | 1222 mm | 1246 mm | 1280 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 693 mm | 696 mm | 709 mm | 719 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 184 cm |
| Rider Max Height | 169 cm | 179 cm | 187 cm | 193 cm |
