Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Tektro Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 165cm
MD
165cm - 172cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Low-Step Design, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Altus 7-Speed RapidFire
Cassette
Shimano, CSHG200, 7-Speed, 11-32T
Crank
Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Kenda. Kwick Seven-5, 27.5”x2.4”, Puncture Protection
Brakes
Brakes
Tektro MDM280 Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy
Handlebar
Marin Alloy, 60mm Rise, 30? Backsweep
Grips
Marin County
Headset
FSA, TH No.10P
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.942 mm | 1.941 mm | 1.937 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm |
| Front Center | 600 mm | 620 mm | 636 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 90 mm | 87 mm | 87 mm |
| Stack | 641 mm | 660 mm | 678 mm |
| Reach | 330 mm | 340 mm | 350 mm |
| Top Tube Length | 602 mm | 620 mm | 640 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 382 mm | 406 mm | 444 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 250 mm |
| Chainstay Length | 485 mm | 485 mm | 485 mm |
| Wheelbase | 1076 mm | 1096 mm | 1113 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm |
| Standover Height | 393 mm | 393 mm | 393 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 165 cm | cm |
| Rider Max Height | 165 cm | 172 cm | cm |
