mason InSearchOf GX Eagle AXS 2024
2024 Road
Estimate price |
5,152$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset GX Eagle, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
42cm
151cm - 164cm
46cm
161cm - 174cm
50cm
170cm - 183cm
54cm
180cm - 190cm
58cm
188cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom-formed Progressive-butted Dedacciai / Reynolds Steel tubeset.
Suspension Fork
Exclusive 'HotShoe' Carbon, ThruAxle, Flat-mount fork with multiple accessory mounts.
Drivetrain
Shift Levers
SRAM Rival AXS Wireless
Cassette
SRAM XG1275 10-52T
Crank
SRAM GX Eagle 34T Boost
Chain
SRAM Eagle 12spd
Wheels
Rims
Mason X HUNT 'The Search'' Dynamo 29" / HUNT 27.5" TrailWide
Tires
WTB Ranger 29 x 2.4 / Ranger 27.5 x 2.8 / Schwalbe choices.
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Ritchey Trail
Handlebar
Ritchey Venturemax Comp
Headset
DEDA Low profile integrated headset.
Seat
Saddle
Fizik Terra Argo X5
Seatpost
MASON Penta carbon, microadjust.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 54cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.653 mm | 1.635 mm | 1.644 mm | 1.649 mm | 1.647 mm |
| Front Center | 628.3 mm | 640.7 mm | 648 mm | 656 mm | 666.3 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm | 67 mm |
| Stack | 606 mm | 614.4 mm | 623.8 mm | 633.1 mm | 654.5 mm |
| Reach | 366.6 mm | 375.7 mm | 379.4 mm | 384 mm | 397.4 mm |
| Top Tube Length | 542.7 mm | 554.1 mm | 560.5 mm | 567.6 mm | 587 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 540 mm | 580 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1062 mm | 1075 mm | 1082 mm | 1090 mm | 1101 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 75 mm | 75 mm | 73 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 151 cm | 161 cm | 170 cm | 180 cm | 188 cm |
| Rider Max Height | 164 cm | 174 cm | 183 cm | 190 cm | 198 cm |
