Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox Pike Select
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 175cm
MD
173cm - 181cm
LG
179cm - 190cm
XL
187cm - 198cm
XXL
195cm - 208cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Frame material: Robust 6061-T6 MAXX Custom Tubing aluminum, double powder-coated for maximum durability and longevity. Designed to withstand the toughest conditions on the trails.
Suspension Fork
Gabel 29" RockShox Pike Select 140mm schw.matt
Rear Shock
Rockshox Deluxe Select Plus TR 185x55, adjustable platform, air spring
Drivetrain
Rear Derailleur
XT Schaltwerk '20 Shadow Plus. schwarz (1X12-fach)
Shift Levers
SLX Schalthebel 20. rechts. 12-fach Schelle
Cassette
SLX Kassette 12 fach 10-51 Z Micro Spline
Crank
XT Tretkurbeleinheit '20 1X12. 30Z.. Boost 170 mm
Chain
SLX Kette 12-fach CNM7100 126 Glieder
Pedals
MAXX Flat Pedal
Wheels
Front Hub
MICHE 550 Boost, through axle 15/110 mm
Rear Hub
MICHE 550 Boost, Through Axle 12/148 mm
Rims
Newman Performance Strong 30, 29" black (30 mm, 32 L)
Tires
Schwalbe Nobby Nic Performace falt 62-622 Addix
Brakes
Brakes
Shimano BR-M6120 4 piston- Disc 203/180 mm
Cockpit
Stem
MAXX MTB 0° oder 7°
Handlebar
e*thirteen Base 800 x 20, 35 mm
Headset
Acros Block-Lock, tapered, w/ 150° steering angle limitation
Seat
Saddle
Selle Italia Man Flow
Seatpost
MAXX Premium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.402 mm | 1.35 mm | 1.316 mm | 1.296 mm | 1.268 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 957 mm | 986 mm | mm | mm | mm |
| Stack | 621 mm | 632 mm | 642 mm | 665 mm | 687 mm |
| Reach | 443 mm | 468 mm | 488 mm | 513 mm | 542 mm |
| Top Tube Length | 572 mm | 599 mm | 622 mm | 652 mm | 687 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm | 540 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 112.5 mm | 125 mm | 150 mm | 175 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1194 mm | 1225 mm | 1250 mm | 1285 mm | 1325 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 164 cm | 173 cm | 179 cm | 187 cm | 195 cm |
| Rider Max Height | 175 cm | 181 cm | 190 cm | 198 cm | 208 cm |
