Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Shimano GRX 800 Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 175cm
MD
173cm - 182cm
LG
180cm - 188cm
XL
186cm - 194cm
XXL
192cm - 200cm
XXXL
198cm - 206cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Robust frame construction / high-quality carbon fork: tested according to MTB standard ISO-4210-2
Suspension Fork
Carbonfork 12 mm thru axle
Drivetrain
Rear Derailleur
GRX rear derailleur RD-RX810, black (2x12)
Front Derailleur
GRX front derailleur FD-RX820 2f, braze-on version
Shift Levers
Brake/shift lever GRX RX 820
Cassette
HG710 cassette, 11-36 Z, 12-speeds
Crank
GRX crankset FC-RX820, 170 mm, 48x31 teeth
Bottom Bracket
BSA, 68mm, threaded
Chain
SLX chain 12-speed CNM7100
Pedals
MAXX Trekking GripLite
Wheels
Front Hub
Hub dynamo disc SP PD6, 32 H, 12 x 100 mm
Rear Hub
Miché R-DX 142 mm SH, TA 12, 32 H
Rims
Newman Performance 25 black (25 mm, 32 L)
Tires
Schwalbe G One Allround Performance 40-622 TLE
Brakes
Brakes
Shimano GRX BRX 820 Flatmount 160/160mm
Cockpit
Stem
MAXX 0° or 8° (12°/16° optional)
Handlebar
MAXX Dropbar
Headset
Acros AZA-638 R4, semi-integr. Alu-Cartridge, tapered
Seat
Saddle
Ergon 'ST 10 Gel', black, 175 mm
Seatpost
MAXX Premium
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL | XXXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.542 mm | 1.53 mm | 1.548 mm | 1.569 mm | 1.586 mm | 1.601 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 760 mm | 775 mm | 786 mm | 792 mm | 802 mm | 811 mm |
| Stack | 572 mm | 595 mm | 616 mm | 637 mm | 658 mm | 679 mm |
| Reach | 371 mm | 389 mm | 398 mm | 406 mm | 415 mm | 424 mm |
| Top Tube Length | 535 mm | 560 mm | 575 mm | 595 mm | 610 mm | 625 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 560 mm | 600 mm | 640 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 185 mm | 205 mm | 225 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1038 mm | 1054 mm | 1066 mm | 1086 mm | 1096 mm | 1106 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 173 cm | 180 cm | 186 cm | 192 cm | 198 cm |
| Rider Max Height | 175 cm | 182 cm | 188 cm | 194 cm | 200 cm | 206 cm |
