Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Suntour XCR 34
-
Groupset Deore, Shimano -
Suspension Full -
Motor Shimano 250W 60Nm mid-drive -
Battery Integrated 500 Litio-ion (Li-ion) 36V - 13,8 Ah - 500 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full integratted Battery, Alloy Triple butted 12x148 BOOST, HORST LINK 4, Wheel travel: 130 mm
Suspension Fork
Suntour XCR 34 air, E-Bike+, travel 130mm, BOOST 15x110, Mini-Fender included
Rear Shock
Suntour Raidon 200x57 Comp. Regul.
Drivetrain
Rear Derailleur
Shimano Deore 6000 10s
Shift Levers
Shimano Deore 6000 10s
Cassette
Shimano Deore 6000 11-42T 10s
Crank
Shimano 34T
Wheels
Front Hub
BOOST system 15x110 12x148 EHL-1485
Rear Hub
BOOST system 15x110 12x148 EHL-1485
Rims
Ready GR 25 TR
Tires
29x2,2
Brakes
Brakes
Shimano MT420 hydraulic disc 4-Piston, 203mm
Cockpit
Stem
3D Forged Alloy, Ext.: 60-70-90 mm, Rise: ±7º
Handlebar
Alloy Butted 31,8x780 mm, Rise: 12 mm, Back sweep: 9º
Headset
FSA Orbit 1,5 E ZS 1-1/8” 1,5”
Seat
Saddle
Megamo
Seatpost
Megamo 30,9 mm
Motor & Battery
Motor
Shimano E7000 250W
Battery
Integrated 500 Litio-ion (Li-ion) 36V - 13,8 Ah - 500 Wh
Remote
Shimano E7000
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.597 mm | 1.502 mm | 1.435 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm |
| Stack | 631 mm | 640 mm | 660 mm |
| Reach | 395 mm | 426 mm | 460 mm |
| Top Tube Length | 575 mm | 610 mm | 644 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Head Tube Angle | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 130 mm | 140 mm | 160 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
AYRON FORCE 40 belongs to the Megamo E Ayron model. There are 3 e-bikes that carry this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The fork installed on this bike is the Suntour XCR 34 model. The travel on this model is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this e-bike has the Suntour Raidon 200×57 Comp. Regul. model, with a travel of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
When it comes to wheels, the AYRON FORCE 40 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AYRON FORCE 40 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
